Convert image to SVG for Cricut and Silhouette

Why Design Space turns your PNG into one solid shape

When you upload a PNG or JPG, Design Space treats it as one flat layer. Choose Cut Image and it keeps only the outer silhouette, so every color, letter and detail inside becomes one solid piece.

Print Then Cut keeps the colors, but the machine still cuts only around the outside, and the printed image is limited to 6.75 x 9.25 in on Letter paper.

If you want a separate piece of vinyl or cardstock for each color, convert the image to SVG for Cricut first. An SVG upload splits into layers you can recolor, hide and cut one at a time.

What Cricut, Silhouette and ScanNCut accept

SVGR downloads SVG or PDF, not DXF. For Cricut, use the SVG. For Silhouette Studio, you need Designer Edition or higher to open it.

Why the holes in your letters fill in, and the Slice fix

SVGR stacks shapes rather than cutting them out. The hole in an O, A or 8 is a separate white shape drawn on top of a solid letter, not a gap in it. On screen it looks right.

In Design Space, hide or delete that white layer and the letter underneath is still solid, so the holes fill in. Transparent background doesn't change this: it removes only the outer background, and enclosed white areas stay.

The fix takes a minute per design:

• Select a white counter and the shape directly below it, then click Slice.
• Delete the leftover white pieces. The letter now has a real hole.
• Repeat for each enclosed shape, or do it once before uploading with Path > Difference in Inkscape.
• The same applies to colors layered over each other: the machine cuts each shape's full outline, including edges hidden underneath. Keep the stack for layered vinyl, or slice when you want pieces that sit side by side.

How to prepare an image for cutting

• Use flat colors. Design Space doesn't support gradients in SVG files, and a gradient-filled shape can upload as a black box.
• Fewer colors mean fewer layers and mats. SVGR has no color-count setting, so reduce the palette in an image editor first if you want, say, exactly three vinyl colors.
• Use the biggest file you have. At low quality, features only a few pixels wide in the source can drop out.
• Crop close to the design and keep the background plain and even, so Transparent background removes it cleanly.

What this won't do

• Filled outlines only. Every line is traced as a thin shape with two edges, so the file is not for Cricut pen, marker or foil single-line drawing: the tool would draw both edges.
• Stacked shapes, not cut-outs. Plan on a Slice step for letters and other enclosed shapes.
• No DXF or EPS, and no offsets or cut borders. Add those in your cutting software.
• Tracing follows your source. A blurry, tiny or heavily compressed JPG gives wobbly edges, so start from the cleanest file you have.
• Transparent background removes the shape painted in the color found at the image corners, which is what people mean by the background. If your artwork bleeds into all four corners, or the corners are different colors, nothing is removed and the background stays — give the artwork a plain, even margin and convert again. Areas fully enclosed by artwork are never removed, and a PNG that already has a transparency channel is left as it is.
• Curves are traced as many short straight segments. Traced from a small image, they can look slightly angular when enlarged, so start from the largest copy you have.
